Image acquisition
Camera, lens, lighting, trigger, and mounting are selected to create stable images before processing.
01 - WHAT IS EVERSIGHT?
An implementation architecture for machine vision systems.
Eversight is an implementation architecture that helps the components of an inspection system work together: stable image acquisition, criterion-based processing, decision-making, and data storage for operational use.
Analysis & Evaluation
Image processing algorithms, AI Vision, OCR or measurements are configured according to agreed error criteria.
Decision Making
The system returns OK/NG results, coordinates, readable codes or signals to be sent to a PLC, robot or rejection mechanism.
Data Storage
Images, result logs, inspection time and traceability data can be stored according to operational requirements.
02 - EVERSIGHT SOLVES WHAT?
Common problems in automated inspection.
Depending on the product and production line, Eversight can be an independent inspection station or part of an existing automation system.
01
Quality inspection
Detecting cosmetic defects, missing/excessive parts, incorrect position, incorrect assembly orientation, or surface abnormalities.
02
Image-based measurement
Measure dimensions, position, angles, distances, or geometric features when non-contact inspection is required.
03
OCR, Barcode & Traceability
Read barcode, QR, Data Matrix, OCR/OCV and link inspection results to each product.
04
Robot guidance & control
Send coordinates, status or processing signals to robots, PLCs, rejection mechanisms and operating systems.
03 - DEPLOYMENT PROCESS
From product samples to a stable operating system.
The process starts with actual samples and specific inspection criteria. Before installation, the technical team needs to determine imaging conditions, processing methods, connection signals, and acceptance procedures.
01
Receive Request
Product, error type, line speed, field of view, tolerance, and connection requirements.
02
Sample Testing
Check camera, lens, lighting, and the ability to distinguish good/bad samples.
03
Configure Eversight
Set up inspection formulas, algorithms, interface, control signals, and data storage methods.
04
Integration & Acceptance
Installation, commissioning, operational training, and acceptance according to agreed-upon criteria.
04 - SYSTEM CONNECTION
Eversight sits between inspection images and actions on the production line.
After receiving results, Eversight can send signals to the PLC, robot, rejection mechanism, or the factory's data system, depending on the project scope.
01
PLC / I/O
Sends OK/NG signals, trigger, interlock, or machine status.
02
Robot
Returns coordinates, angles, recognition status, or gripping instructions.
03
Rejection mechanism
Sorts out defective products by time, location, or product code.
04
Production data
Saves images, results, trace codes, and reports according to operational needs.
